FAN ACCESSORIES

SMOKE CURTAINS


U.S. Patent #7810576


THE SMOKE BLOCKAID —
THE ULTIMATE SMOKE CURTAIN

The patented Smoke BlockAid sets up in seconds, helping control oxygen to the fire for efficient door control while containing smoke to a single room to minimize property damage.


  1. Oxygen Control to the Fire: Sets up in seconds and requires no manpower to maintain door control and provide visual indicator of flow path; reduces smoke spread in common areas to help with rescue operations and prevents smoke spread in large buildings
  2. Perfect for Uni-Directional Ventilation Scenarios: Forces airflow into the room at a lower volume rate, drastically minimizing conditions that lead to flashover
  3. Passable Entryway: Allows personnel and charged hose lines to pass through the doorway while the SmokeBlockAid is deployed
  4. Replaceable Fabric: Rated up to 500° F (260° C)

SMOKE BLOCKAID OPTIONS

SEE SUPER VAC’S SMOKE CONTAINMENT CURTAIN IN ACTION …

smoke curtain options


Scroll right for full chart.


SmokeBlockAidMin
Width
Max
Width
HeightMaterialRatchet
S-10027"
68.5 cm
43"
109 cm
75"
1.9 m
Replaceable silicone impregnated fiberglass, rated up to 500° F (260 ºC) for extended period of time.
Fabric maintains integrity up to 1,100° F (594º C)
QuickAction with
screw tightening
S-15036"
91 cm
56"
142 cm
75"
1.9 m
